Parker Instrumentation Tube Fittings are designed are leak-free connections for process, power, and oil gas instrumentation applications handling liquids, gases and chemicals.
Parker’s instrument tube fittings have been engineered and manufactured to consistently provide the highest level of reliability. However, no system’s integrity is complete without considering the critical link, tubing.
Proper tube selection and installation are key ingredients in building leak-free reliable tubing systems. Parker Instrument fittings are designed to work on like materials therefore, stainless steel fittings should be used only with stainless steel tubing. The practice of mixing materials is strongly discouraged. The only exception is brass fittings with copper tubing.
Showing 1–9 of 14 results
Parker Autoclave Engineers Low Pressure “Speedbite” and “Mini” Series fittings are designed to work with 10V/SW Series and Mini Series Low Pressure Valves as well as Low Pressure Tubing made of commercially sized 316/316L SS in the “Annealed” condition. Pressures to 15,000 psi and sizes from 1/16″ to 1/2″ are readily available.
The Speedbite connection is a single-ferrule bite-type compression fitting engineered for use with tubing designed by Parker Autoclave Engineers to a controlled hardness. Speedbite fittings employ a bite-type compression style single ferrule that is manually tightened.
Parker Autoclave Engineers use high quality UNS S31600/S31603 316/316L material cold worked to our stringent specifications that enable certification of NPT style Instrument Pipe Fittings to a maximum working pressure of 15,000 psi (1050 bar). It’s the strength of the material that allows this superior pressure rating and care should be taken to only use with other similar fittings made to the same specification.
The Parflare Fittings are ideally suited for any ultrapure or corrosive chemical application. The fitting design yields a leak tight connection with minimal dead volume and can be used in side loading and vibrational applications. The connection is achieved by a heated flaring process utilizing an external heat source (HG Heat Gun) and PTFE mandrel (MFT Manual Flaring Tool), or by using Partek’s optional FG Series Electronic Flare Gun. Parflare PFA fittings are supplied with PVDF nuts as standard. For PFA nuts add -T suffix to part number. For High Temperature nut assemblies add -HT suffix to part number (1/4” – 1” sizes only).
